Lead-free 4 Heating Zones Smt/smd Led Full Hot Air Reflow Oven SMT
reflow Soldering For Production line of electronic products
Product Introduction
1. Imported high current relay without contact output, safe and
reliable, equipped with special SSR radiator, heat dissipation
efficiency greatly improved, effectively extend its service life.
2. The heating parts adopt imported high quality components to
ensure the high stability and reliability of the system and ensure
a longer service life.
Heating Modular design for easy maintenance.
3. With temperature difference, fault diagnosis, sound and light
alarm function.
4. Independent small circulation air transport design, up and down
heating mode, good thermal compensation, high thermal efficiency,
power saving, heating speed. Special forced hot air circulation
structure system, make PCB and components heating evenly, high
efficiency, fast heating speed.
5. The air transportation system adopts the advanced air duct
design, the air transportation is even, the heat exchange
efficiency is high.
6. Preheating zone, welding zone and cooling zone up and down
independent heating, independent cycle, independent temperature
control, not string temperature, temperature of each temperature
zone can be adjusted independently.
7. Imported high-temperature motor direct drive hot air cycle, hot
air balance, smooth operation, long life, low noise.
8. The power of each temperature area is matched properly, the
temperature is raised quickly, from room temperature to set working
temperature about 20 minutes. And has a fast and efficient thermal
compensation performance.
9. The transmission system adopts the speed regulating motor and
the imported 1:150 turbine reducer, which runs smoothly and the
speed can be adjusted in the range of 300-2000mm/min.
10.Eleven. Adopt independent roller structure and support, combined
with stainless steel mesh belt, running smoothly.
11.Twelve. Special stainless steel mesh belt, wear-resistant. Long
time use not easy to change shape.
Product Specification
Technical Parameters |
Model | H4430A |
Control method | Meter |
Number of heating zones | 4 small circulation heating zones up and down |
Heating method | Hot air up and down |
Heating zone length | 1400MM |
Conveyor belt width | 300mm |
PCB size | 50-300MM |
PCB limit height | 25mm |
Transmission direction | Left to right |
Transmission method | Mesh belt |
Conveyor belt height | 900±20MM |
PCB shipping speed | 0～1.8m/min |
Temperature Control Accuracy | ±1-2°C (static) |
Temperature control range | Can be set from room temperature to 300°C |
Applicable solder type | Lead-Free Solder/Leaded Solder |
Temperature control method | PID+SSR |
Power supply | 3Φ, 380V, 50HZ |
Starting power | 18KW |
Operating power | 5-8KW |
Running speed | Approx.20min |
Shape | L2500*645*1350MM |
Weight | 300kg |
Body color | The whole machine adopts computer white and frame black. |
